- Product information
General data
Type
Display
Power button
Yes
Display
Display size
12.1"
Display type
TFT
Aspect ratio
4:3
Display colors max
262k
Display resolution
800x600
Display brightness
400cd/㎡
Backlight type (typical)
LCD
Touchscreen
Resistive
Multitouch
No
Touch Interface
USB
Video Interface
VGA / HDMI
Contrast ratio
800:1
Viewing angle
80(L) 80(R) 60(U) 80(D)
Additional Interfaces
Speaker-out
1
OSD function
OSD
5 Keys
Power supply
Power supply V DC
12V DC
Power supply connector
Power Cord C20
Power consumption typical
20 W
Physical characteristic
Housing material
Aluminium; Metal
Housing color
Silver/ Black
Ingress protection
IP65 Front
Dimensions (W x H x D)
330x256x44 mm
Weight
3.5kg
Mounting
VESA 75/100/Panel mount/customized
Environmental
Operating temperature range
-20-+60℃
Storage temperature range
-40-+85℃
Humidity
95%
Vibration
1Grms,5~500Hz
Shock
10G ,11ms
