- Product information
General data
Type
Display
Power button
Yes
Series
YHJD7
Display
Display size
7"
Display type
TFT
Aspect ratio
16:9
Display colors max
16.7M
Display resolution
1024x600
Display brightness
250cd/©O
Backlight type (typical)
LED
Touchscreen
Capacitive
Multitouch
10 points
Touch Interface
USB
Video Interface
VGA / DVI-D / HDMI
Contrast ratio
1000:1
Viewing angle
80(L) 80(R) 75(U) 75(D)
Additional Interfaces
Speaker-out
1
OSD function
OSD
5 Keys
Power supply
Power supply V DC
12V DC
Power supply connector
Power Cord C20
Power consumption typical
18 W
Physical characteristic
Housing material
Aluminium
Housing color
Silver
Ingress protection
IP65 front panel
Dimensions (W x H x D)
188x125x31(mm)
Weight
3kg
Mounting
VESA 75/100/Panel mount/customized
Environmental
Operating temperature range
-20-+60¡æ
Storage temperature range
-40-+85¡æ
Humidity
95%
Vibration
1Grms,5~500Hz
Shock
10G ,11ms
