- Product information
General data
Type
Networking Appliance
Series
NAD
Cooling
Fanless
Processor system
CPU type
Intel® Celeron™ J1900
CPU generation
Bay Trail
CPU family
Intel® Celeron™
CPU socket
Soldered
CPU frequency
2.0 GHz
CPU frequency max
2.42 GHz
CPU cores
4
L2 cache
2 MB
Hyperthreading
No
Embedded
Yes
TDP
10W
Graphics
Intel HD Graphics
Audio
No
Watch dog
No
Memory / RAM
Socket type
SO-DIMM
Number of slots
1
Storage type
DDR3
ECC
No
Frequency
1333MHz/1600MHz
Voltage
1.5V
Capacity
2G(up to 8Gb)
Storage
Bays
2
Slot Msata
1
Slot SATA2.0
1
Ethernet
Lan chipset
Intel I211-AT Gigabit LAN
Number of Lans
4
Front I/O
Power button
1
LED
1xpower LED
VGA
1
USB
1xUSB3.0,3xUSB2.0
Audio
No
Rear I/O
POWER
1xDC Jack
LED
1xpower LED, 1xHDD LED
LAN Chipset
4xRJ-45
Expansion
mPCIe Full Size
1
SIM Card Slot
1
Automatically Boot Jumper
1
DC-in
Header(optional)
OS Support
OS
Windows7,Windows8,Windows 10,Linux
Power supply
Power supply V DC
12V/3A
Power supply connector
DC Jack/5.5mm,2.5mm
Physical characteristic
Housing material
Aluminium
Housing color
Black
Dimensions (W x H x D)
156x127x37mm
Weight
0.85kg
Mounting
VESA Mounting Bracket
Environmental
Operating temperature range
0-+50¡æ
Storage temperature range
-20-+80¡æ
Humidity
95%
