- Product information
CPUGeneral data
Type Mainboard
Series YHMB1
Storage Yes
CPU type
Intel Atom X5- Z8350
CPU generation
Cherry trail
CPU family
Intel Atom
CPU socket
Soldered
CPU frequency
1.44GHz
CPU frequency max
1.92GHz
CPU cores
4
L2 Cache
2M
Hyperthreading
No
Embedded
Yes
Memory
Socket type
On board integrated
Storage type
DDR3
Frequency
1333MHz / 1600MHz
Voltage
1.5V
Capacity
2GB / 4GB
Storage
eMMC
32GB / 64GB integrated
Graphics
Graphic type
On board integrated
Graphic chip (GPU)
Intel® HD Graphics
Graphic memory
Shared
VGA
1
LVDS
0
HDMI
1
Amount simultaneous displays
2
Resolution
1920 x 1080
Ethernet
10 100 / 1000 base ports
1
Connector TX
RJ-45
Wi-Fi and Bluetooth
Wi-Fi
Realtek RTL8111FLAN
Bluetooth 4.0
1
I/O interfaces
DC-IN
1
HDMI
1
VGA
1
RJ45
1
Power button
1
Power switch
1
LED
1
TF Card Slot
1
USB 2.0
1
USB 3.0
1
Micro USB
1
Audio (Mic-in, Line-out)
1
Power Supply
Power supply V DC
5V / 3A DC
Power supply connector
DC IN
Physical characteristic
Dimension
Accessories
105x70 mm
No
Environment
Operating Temperature
0-50 ¡æ
Storage temperature
-10-60 ¡æ
Humidity
95%
